Yii Framework

Padawan Guide

Created by Jorge Barata González

Overview

• Fundamentals
• Models
• Database
• Scaffolding

MVC

MVC

Model View Controller

MVC

Web Applications

• Most common architecture for World Wide Web in all major programming languages
• Application frameworks enforce the pattern

Yii Framework

Yii Framework

Documentation

http://www.yiiframework.com/doc

The Definitive Guide to Yii

The Yii Blog Tutorial

Yii Framework

MVC

Yii Framework

git clone git@github.com:yiisoft/yii.git


yii/framework/yiic webapp ./padawan


Create dummy database

mkdir data
touch data/testdrive.db


Yii Framework

Directory Structure

assets
protected/
	components
	config
	controllers
	models
	runtime
	views


Yii Framework

Directory Structure

assets
protected/
	components
	config
	controllers	*
	models 		*
	runtime
	views 		*


Yii Framework

Workflow

Workflow

Workflow

Entry script

<?php
// remove the following line when in production mode
defined('YII_DEBUG') or define('YII_DEBUG',true);
// include Yii bootstrap file
require_once('path/to/yii/framework/yii.php');
// create application instance and run
$configFile='protected/config/main.php';
Yii::createWebApplication($configFile)->run();


Configuration

Array based:

<?php return array(...


Required by the entry script:

index.php         ->   protected/config/main.php
index-test.php    ->   protected/config/test.php


Workflow

Create a new action named padawan inside site controller

protected/controllers/SiteController.php

<?php
class SiteController extends Controller {
	...
	public function actionPadawan() {
		echo 'May the force be with you';
	}
}


http://localhost/lightsaber/?r=/site/padawan

Yii Framework

Model

Models

CModel

• Attributes
• Rules
• Validation
• Scenario

Form Models

CFormModel

• Extends CModel
  • Default attribute names

protected/models/ContactForm.php

Yii Framework

Migrations

Migrations

Database schema versioning

• Class based, extends CDbMigration
  • up()
  • down()

Migrations

m<timestamp>_<name>

<?php
class m130719_124500_lightsaber extends CDbMigration
{
    public function up()
    {
        $this->createTable('Lightsaber', array(
            'id' => 'pk',
            'color' => 'string NOT NULL',
        ));
        $this->execute('INSERT INTO ');
    }

    public function down()
    {
        $this->dropTable('Lightsaber');
    }
    ...


Migrations

Example

#Create migration
protected/yiic migrate create lightsaber


...edit migration...

#Apply migration
protected/yiic migrate

#Revert migration
protected/yiic migrate down


Active Record

Active Record

Architectural pattern for database access

• Class → Table
• Object → Record

Active Record ∈ ORM (Object Relational Mapping)

Active Record

Cons

• Unit testing an active record object without a database becomes difficult

Yii Framework

Active Record

Active Record

Yii Framework

CActiveRecord

• Extends CModel
  • Default attribute names
  • Database access
    • find()
    • save()
    • delete()
    • getRelated()
    • ...

Active Record

Yii Framework

protected/models/Lightsaber.php

<?php
class Lightsaber extends CActiveRecord {
    public static function model($className=__CLASS__)
    {
        return parent::model($className);
    }
}


Active Record

Yii Framework

model() returns an AR instance that is used to access class-level methods (something similar to static class methods) in an object context

Active Record

Yii Framework

<?php
#New row
$model = new Lightsaber;
$model->color = 'blue';
$model->save();

#Update row
$model = Lightsaber::model()->find('color=:color', array(':color'=>'blue'));
$model->color = 'red';
$model->save();

#Delete row
$model = Lightsaber::model()->findByAttributes(array('color'=>'red'));
$model->delete();


Active Record

Yii Framework

				count()
				exists()

				find()
				findByPk()
				findAll()
				findAllByAttributes()

				updateAll()
				updateByPk()
				updateCounters()

				deleteAll()
				deleteByPk()


Yii Framework

Gii

Gii

Web-based code generation tool

• Controllers
• CRUD
• Form
• Model
• ...

Gii

protected/config/main.php

<?php
return array(
    ...
    'modules'=>array(
        'gii'=>array(
            'class'=>'system.gii.GiiModule',
            'password'=>'darth vader',
            ...
        ),
    ),
    ...
);


Gii

http://localhost/lightsaber/?r=/gii

• Generate the Lightsaber model
• Generate CRUD
• http://localhost/lightsaber/?r=/lightsaber

THE END
